Battery Analyzer

BT-780 Battery Analyzer is delicately developed to test 12V regular flooded, AGM flat plate, AGM spiral and gel batteries and 12V & 24V starting and charging system.

It provides a quick, easy and affordable solution for technicians to check battery health and detect faults of starting and charging system.

Features and Benefits

● Dedicatedly developed to test start-stop AGM and EFB batteries

● More convenient and accurate with advanced conductance test technology

● Ripple voltage test allows the technicians to check the output voltage of alternator quickly

● Built-in thermal printer to print test results at anytime and anywhere

● SOC and SOH tests make technicians easier and faster to judge the battery status.

● Equipped with 0-1000A AC and DC current clamp (optional)

● Replaceable test cables

● Tests multiple battery types - regular flooded, AGM flat plate, AGM spiral and gel, start-stop AGM and EFP batteries

● Tests multiple rating systems - CCA, CA, MCA, JIS, DIN, IEC, EN, SAE

● Quick and accurate test results display in just 3 seconds

● Applicable for 12V battery system and 12V & 24V starting and charging system

● Advanced starter/alternator test

● Quick starter analysis without disabling the ignition

● Does not emit light, heat or spark, or discharge battery - keeps operation safe for all levels of users

● Multilingual menu and test results

Voltage measuring6V to 32VN/A
Battery typeFlooded, AGM, GEL, start-stop
AGM & EFB  batteries
Battery rating100 - 2000CCA±(3%+5) CCA
Standard supportCCA, CA, MCA, JIS, DIN, IEC, EN, SAEN/A
Net weight0.8kgN/A




Battery Analyzer
