Support By Vehicle
911
| Sensor manufacturer | 433MHz |
| Sensor frequency | |
| Sensor part number | 5Q0907275 |
| Sensor printing number | RDE018 |
| Learning type | O/A |
| Tire nut torque value (Nm) | 133-168 |
Relearn Procedure:
vehicles with multi-function steering wheel
The settings must be updated in the 'Tire pressure' menu after changing a wheel, wheel transmitter replacement, filling with tire sealant, update of the tire settings or adding air (after previous warning 'Tire pressure!') .
1. Turn ignition to ON position (engine off) .
2. Press the rotary knob at right of steering wheel entry Main menu, turning the rotary knob upwards or downwards to select Tire pressure, and press the rotary knob confirm the selection.
3. Select 'Fill info' and confirm: You can read the tire pressure to be corrected on this display. The tire pressure to be corrected (refill pressure) is indicated on the displayed wheel. Example: If '--1. 5 psi'/'--0. 1 bar' is displayed for the rear right tire, 1. 5 psi/0. 1 bar/10 kPa must be added to this tire. The displayed pressures take into account the tire temperature.
4. Select 'Adjust' and confirm: select Summer tires or Winter tiers or All-season and confirm, selecting the tire size and confirm. ( Information on the size and type can be found on the tire sidewall) . Tire selection has only been successfully completed when the following message appears on the multi-function display, example: 'Summer tires 19-inch was set. No monitoring, system is learning'.
Note: The new tire type and tire size must be selected even if the settings for the new set of wheels are the same as for the old wheels.
5. The wheel learning process takes place exclusively when the vehicle is being driven (vehicle speed should be above 16 mph (25 km/h) and under 64 mph (100 km/h) ) .
Tire Pressure Monitoring requires a certain amount of time to learn the wheels. During this time, the current tire pressures are not available on the multi-function display:
The tire pressure warning light remains lit until all wheels have been learned.
Lines (-. -) appear on the display of the 'Tire pressure' function.
Position and pressure information is displayed as soon as Tire Pressure Monitoring has assigned the wheels recognised as belonging to the vehicle to the correct wheel positions.
CN Audi A1 2014.09~2014.12(433MHz)
CN/US Audi A3 2019.01~2023.12(433MHz)(MLB)
AU/EU/KR/RU/US Audi A3 2012.06~2023.12(433MHz)
CN Audi A3 2010.01~2019.12(433MHz)
AU/CN/EU/JP/KR/RU/US Audi A4 2012.01~2023.12(433MHz)
CN Audi A4 Allroad 2016.01~2019.12(433MHz)(MLB)
AU Audi A4 Allroad 2015.01~2023.12(433MHz)
EU/RU Audi A4 Allroad 2009.03~2023.12(433MHz)
EU/RU/US Audi A4 Avant 2015.01~2022.06(433MHz)
CN Audi A4L 2016.01~2021.12(433MHz)
KR/US Audi A5 2019.01~2023.12(433MHz)
CN Audi A5 2017.01~2022.12(433MHz)
CN Audi A5 2013.01~2013.12(433MHz)
AU/CN/EU/RU Audi A5 2006.09~2023.12(433MHz)
US Audi A6 2019.01~2022.12(433MHz)(5Q0907275)
KR Audi A6 2018.01~2023.12(433MHz)(4G)
CN Audi A6 2011.01~2023.12(433MHz)(4G)
AU/EU/RU Audi A6 2011.01~2023.12(433MHz)
EU/RU Audi A6 Allroad 2018.10~2023.12(433MHz)(5Q0907275)
AU/CN/EU/JP/KR/RU/US Audi A6 Allroad 2016.01~2023.12(433MHz)(MLB)
EU/RU Audi A6 Avant 2017.07~2023.12(433MHz)
EU/RU Audi A6 Quattro 2011.01~2015.12(433MHz)
CN Audi A6L 2020.01~2023.12(433MHz)
CN/US Audi A7 2018.01~2023.12(433MHz)(5Q0907275)
AU/EU/KR/RU Audi A7 2010.09~2023.12(433MHz)(5Q0907275)
KR Audi A8 2017.01~2023.12(433MHz)
AU/CN/EU/RU/US Audi A8 2010.01~2023.12(433MHz)(5Q0907275)
AU Audi A9 2019.01~2019.12(433MHz)
EU/RU Audi C-MPV 2009.03~2018.12(433MHz)
CN/EU/RU/US Audi e-tron GT 2022.04~2024.12(433MHz)
KR Audi Q2 2020.01~2023.12(433MHz)
JP Audi Q2 2017.01~2023.12(433MHz)
AU/CN/EU/RU/US Audi Q2 2016.01~2023.12(433MHz)
KR Audi Q3 2020.01~2023.12(433MHz)
CN Audi Q3 2017.01~2022.12(433MHz)
AU/CN/EU/RU/US Audi Q3 2011.07~2023.12(433MHz)
AU/EU/RU/US Audi Q4 2019.09~2023.12(433MHz)
KR/US Audi Q5 2017.01~2023.12(433MHz)
CN Audi Q5 2017.01~2019.12(433MHz)
AU/CN/EU/RU Audi Q5 2008.09~2023.12(433MHz)
AU/CN/JP/KR/US Audi Q5L 2016.01~2022.12(433MHz)(MLB)
CN/EU/RU Audi Q6 2022.06~2023.12(433MHz)
AU Audi Q6 2018.01~2019.12(433MHz)
JP Audi Q7 2017.01~2017.12(433MHz)
AU/CN/EU/JP/KR/RU/US Audi Q7 2015.01~2023.12(433MHz)(MLB)
KR Audi Q7 2015.01~2023.06(433MHz)(4L.AU726)
EU/RU Audi Q7 2015.01~2021.12(433MHz)(4L.AU726)
CN Audi Q7 E-Tron 2015.01~2016.12(433MHz)
AU/CN/EU/JP/KR/RU/US Audi Q8 2018.01~2023.12(433MHz)
AU/CN/JP/KR/US Audi Q9 2021.01~2022.12(433MHz)
EU/KR/RU Audi R8 2015.04~2023.12(433MHz)
CN Audi RS Q3 2021.01~2022.12(433MHz)
AU/EU/JP/RU/US Audi RS Q3 2013.01~2023.12(433MHz)
AU/EU/RU/US Audi RS Q8 2019.12~2023.12(433MHz)
AU/CN/EU/RU/US Audi RS3 2016.07~2023.12(433MHz)
EU/RU/US Audi RS4 2015.01~2023.12(433MHz)(5Q0907275)
AU Audi RS4 2006.04~2021.12(433MHz)
AU/CN/EU/JP/KR/RU/US Audi RS5 2017.01~2023.12(433MHz)
AU Audi RS5 2012.01~2022.12(433MHz)
US Audi RS6 2021.01~2023.12(433MHz)
AU/EU/RU Audi RS6 2019.01~2023.12(433MHz)(5Q0907275)
EU/RU/US Audi RS6/RS6 Plus 2020.01~2020.03(433MHz)
US Audi RS7 2021.01~2023.12(433MHz)
AU/EU/RU/US Audi RS7 2018.03~2023.12(433MHz)
CN Audi S3 2018.06~2019.12(433MHz)
CN Audi S4 2022.01~2022.12(433MHz)
EU/RU Audi S4 2015.01~2023.12(433MHz)
AU Audi S4 2009.01~2019.12(433MHz)
CN Audi S5 2020.01~2020.12(433MHz)
EU/RU/US Audi S5 2018.01~2023.12(433MHz)
AU/CN/JP/KR/US Audi S5 2012.01~2019.12(433MHz)
CN Audi S5 2012.01~2018.12(433MHz)
EU/RU Audi S6 2018.06~2023.12(433MHz)
KR Audi S6 2018.01~2019.12(433MHz)
EU/RU Audi S7 2018.01~2024.12(433MHz)
EU/KR/RU Audi S8 2017.10~2023.12(433MHz)
EU/RU/US Audi SQ2 2017.01~2019.12(433MHz)
KR Audi SQ5 2017.01~2023.12(433MHz)
AU/CN/EU/JP/KR/RU Audi SQ5 2014.01~2023.12(433MHz)
AU/EU/RU/US Audi SQ7 2016.01~2023.12(433MHz)
AU/EU/RU/US Audi SQ8 2020.01~2023.12(433MHz)
AU/CN/EU/KR/RU/US Audi TT 2014.02~2023.12(433MHz)
CN Audi TT 2012.01~2020.12(433MHz)
AU/CN/EU/JP/KR/RU/US Audi TT RS 2016.11~2023.06(433MHz)
AU/CN/EU/JP/KR/RU/US Audi TTS 2014.01~2023.12(433MHz)
AU/CN/EU/JP/KR/RU/US Bentley Bentayga 2016.01~2023.12(433MHz)(5Q0907275)
KR Bentley Continental GT 2022.01~2023.12(433MHz)
AU/CN/EU/JP/KR/RU/US Bentley Continental GT 2018.04~2024.12(433MHz)
AU/CN/EU/JP/KR/RU/US Bentley Continental GTC 2018.01~2023.12(433MHz)(5Q0907275)
AU/CN/EU/KR/RU/US Bentley Flying Spur 2019.01~2024.12(433MHz)(5Q0907275)
AU/CN/EU/RU/US Bentley Mulsanne 2017.01~2022.12(433MHz)
EU/RU/US Ferrari F588 Dino 2019.01~2022.12(433MHz)(Huf.Beru)
KR Ferrari GTC4 Lusso 2016.01~2020.12(433MHz)
KR/US Ferrari Portofino 2016.01~2023.12(433MHz)
KR Lamborghini Urus 2020.01~2024.12(433MHz)
JP Lamborghini Urus 2019.01~2024.12(433MHz)
AU/CN/EU/RU/US Lamborghini Urus 2018.01~2024.12(433MHz)
EU/RU/US MAN TGE 2017.01~2022.12(433MHz)(5Q0907275B)
EU/RU Maserati GranTurismo Sport 2019.01~2023.12(433MHz)
EU/RU Maserati GranTurismo Sport 2017.08~2018.12(433MHz)
AU/CN/EU/JP/KR/RU/US McLaren 500 Series 2015.01~2024.12(433MHz)(RDE018)
CN McLaren 570GT 2017.01~2020.12(433MHz)
CN/US McLaren 570S 2016.01~2022.12(433MHz)
AU/CN/EU/JP/KR/RU/US McLaren 700 Series 2017.01~2024.12(433MHz)
US McLaren 720S 2017.01~2022.12(433MHz)
CN/EU/RU/US Porsche 718(982) 2016.01~2024.12(433MHz)
AU/CN/EU/JP/KR/RU/US Porsche 911 2017.01~2022.12(433MHz)
EU/KR/RU Porsche 911 2015.01~2020.12(433MHz)
AU/CN/EU/RU/US Porsche 911(991) 2017.01~2020.12(433MHz)
CN Porsche 911(991) 2013.01~2013.12(433MHz)
EU/RU Porsche 911(992) 2019.01~2024.12(433MHz)
AU/CN/KR/US Porsche 911(992) 2017.01~2024.12(433MHz)
CN/EU/KR/RU/US Porsche 911(997) 2015.09~2019.12(433MHz)
CN/EU/RU/US Porsche 911(Turbo) 2017.01~2021.12(433MHz)
US Porsche 918 Spyder 2014.01~2016.12(433MHz)(5Q0907275)
AU Porsche 960 2015.09~2019.06(433MHz)
CN/EU/KR/RU/US Porsche Boxster 2016.03~2024.12(433MHz)(982.982SP)
AU/CN/EU/JP/KR/RU/US Porsche Cayenne 2017.08~2023.12(433MHz)
AU/CN/KR/US Porsche Cayenne 2014.11~2017.08(433MHz)
EU/RU Porsche Cayenne 2014.08~2017.08(433MHz)
CN/EU/KR/RU/US Porsche Cayenne S 2017.09~2023.12(433MHz)
CN/EU/KR/RU/US Porsche Cayenne S 2014.06~2017.08(433MHz)
EU/RU Porsche Cayman 2014.05~2016.12(433MHz)(GTS)
CN/EU/KR/RU/US Porsche GT3 2017.01~2021.12(433MHz)
AU/CN/EU/KR/RU/US Porsche Macan 2013.07~2023.12(433MHz)
AU/CN/EU/JP/KR/RU/US Porsche Panamera 2013.09~2023.12(433MHz)(970.971)
AU/CN/KR/US Porsche Panamera 2017.01~2023.12(433MHz)
AU/CN/EU/KR/RU/US Porsche Panamera 2013.09~2017.08(433MHz)
AU/CN/EU/JP/KR/RU/US Porsche Taycan 2019.01~2024.12(433MHz)
EU/RU Skoda Citigo 2014.05~2020.06(433MHz)
EU/RU Skoda Citigo 2011.10~2020.12(433MHz)
AU/CN/EU/RU Skoda Fabia 2015.01~2021.12(433MHz)
AU/EU/RU Skoda Fabia 2013.10~2014.12(433MHz)
EU/RU Skoda Kamiq 2019.09~2020.12(433MHz)
CN/EU/RU Skoda Karoq 2017.05~2023.06(433MHz)
AU/CN/EU/JP/KR/RU/US Skoda Kodiaq 2016.01~2023.06(433MHz)
EU/RU Skoda Octavia 2015.01~2023.12(433MHz)
AU/CN/EU/RU Skoda Octavia 2012.10~2014.12(433MHz)
EU/RU Skoda Rapid 2015.05~2022.12(433MHz)
AU/CN/EU/JP/KR/RU Skoda Rapid 2012.01~2017.04(433MHz)
AU/EU/RU Skoda Roomster 2006.01~2018.12(433MHz)
AU/CN/EU/RU/US Skoda Superb 2017.01~2023.12(433MHz)
AU/EU/RU Skoda Superb 2015.05~2023.12(433MHz)
US Skoda Superb 2015.05~2022.12(433MHz)
AU/EU/RU/US Skoda Superb 2008.03~2015.04(433MHz)
AU/CN/EU/JP/KR/RU Skoda Yeti 2009.06~2018.12(433MHz)
AU/CN/EU/JP/KR/RU/US Volkswagen Amarok 2016.01~2024.12(433MHz)
EU/RU/US Volkswagen Amarok 2009.11~2018.02(433MHz)
AU/CN/JP/KR/US Volkswagen Atlas 2017.01~2023.12(433MHz)
AU/CN/EU/JP/KR/RU Volkswagen Beetle 2012.12~2019.12(433MHz)
AU/CN/EU/JP/KR/RU/US Volkswagen Caddy 2003.12~2024.12(433MHz)
AU/CN/EU/RU Volkswagen Caravelle 2019.11~2023.12(433MHz)
AU/CN/EU/JP/KR/RU Volkswagen Caravelle 2003.01~2018.12(433MHz)
AU/CN/EU/KR/RU/US Volkswagen CC 2018.01~2023.06(433MHz)(MQB)
AU/CN/EU/JP/KR/RU/US Volkswagen Crafter 2014.07~2023.12(433MHz)
AU/CN/EU/JP/KR/RU Volkswagen Cross Blue 2016.04~2019.12(433MHz)
EU/RU Volkswagen EOS 2006.02~2018.06(433MHz)
AU/CN/EU/JP/KR/RU/US Volkswagen Golf 2009.01~2023.12(433MHz)
AU/CN/US Volkswagen Jetta 2013.01~2019.12(433MHz)
EU/RU Volkswagen Jetta 2010.07~2023.12(433MHz)
AU/CN/JP/KR Volkswagen Lamando 2015.01~2023.12(433MHz)
AU/CN/EU/JP/KR/RU Volkswagen Magotan 2016.01~2023.06(433MHz)(5Q0907275B)
AU/CN/EU/RU Volkswagen Multivan 2004.03~2015.12(433MHz)
AU/EU/KR/RU Volkswagen New Beetle 2011.08~2020.06(433MHz)
AU/CN/EU/JP/KR/RU/US Volkswagen Passat 2014.09~2023.12(433MHz)(B8)
EU/RU Volkswagen Passat CC 2014.09~2022.12(433MHz)
AU Volkswagen Passat CC 2014.09~2019.12(433MHz)
AU/CN/EU/RU/US Volkswagen Polo 2017.09~2023.12(433MHz)
AU/CN/EU/KR/RU/US Volkswagen Santana 2014.09~2023.12(433MHz)
AU/EU/RU Volkswagen Scirocco 2008.01~2019.12(433MHz)
EU/RU Volkswagen Sharan 2008.01~2020.06(433MHz)
AU Volkswagen T5 2014.03~2019.12(433MHz)
AU/CN/EU/JP/KR/RU Volkswagen Tayron 2019.01~2023.12(433MHz)
CN Volkswagen Tayron GTE 2021.01~2021.12(433MHz)
AU/CN/EU/JP/KR/RU Volkswagen Teramont 2017.01~2023.12(433MHz)
AU/CN/EU/JP/KR/RU/US Volkswagen Tiguan 2016.01~2023.12(433MHz)(VW376.5N2)
KR Volkswagen Tiguan 2016.01~2023.12(433MHz)
AU/CN/EU/JP/KR/RU/US Volkswagen Tiguan L 2016.01~2023.12(433MHz)
AU/CN/JP/KR Volkswagen Tiguan X 2018.01~2020.12(433MHz)
AU/CN/US Volkswagen Touareg 2014.08~2023.12(433MHz)(7P5/7P6108)
EU/KR/RU/US Volkswagen Touareg 2014.08~2023.12(433MHz)
AU/EU/RU Volkswagen Touran 2015.01~2023.12(433MHz)
AU/CN/EU/JP/KR/RU Volkswagen Touran L 2018.01~2019.12(433MHz)
EU/RU Volkswagen Transporter 2003.04~2018.02(433MHz)
AU/EU/RU Volkswagen Up! 2011.08~2018.12(433MHz)
AU/CN/JP/KR Volkswagen Variant 2009.01~2023.12(433MHz)
EU/RU Volkswagen XL1 2013.07~2018.09(433MHz)
CN Audi A7 Quattro 2018.01~2023.12(433MHz)(5Q0907275)
EU/RU McLaren 570S 2017.01~2018.12(433MHz)
AU/CN/JP/KR McLaren 540C 2015.01~2023.12(433MHz)
EU/RU/US Audi A6 2018.01~2023.12(433MHz)
EU/RU/US Audi E-tron 2009.01~2023.12(433MHz)
AU/CN/EU/JP/KR/RU/US Audi Q1 2016.01~2020.12(433MHz)
AU/CN/EU/JP/KR/RU/US Porsche 991 2017.01~2022.12(433MHz)
AU/CN/EU/RU/US Volkswagen Touareg 2014.08~2023.12(433MHz)(7P)
US Volkswagen Touareg 2 2015.01~2019.12(433MHz)
AU/CN/EU/JP/KR/RU Skoda Praktik 2016.01~2020.12(433MHz)
AU/CN/EU/JP/KR/RU/US Audi E-tron 2019.09~2023.12(433MHz)
CN Porsche Cayenne 2024.01~2024.12(433MHz)
AU/CN/EU/KR/RU/US Porsche Cayman 2016.10~2024.12(433MHz)(982/982C/CT4-2)
