Acadia

Support By Vehicle

Acadia

Description

Technical Support

Other Vehicles Uses This Sensor

Sensor manufacturer	315MHz
Sensor frequency
Sensor part number	15268606
Sensor printing number	15268606
Learning type	O/S
Tire nut torque value (Nm)	120

There are two minutes to match the first tire position, and five minutes overall to match all four tire positions. If it takes longer, the matching process stops and must be restarted.

Relearn Procedure:

1. Set the parking brake.

2. Turn ignition to ON position (engine off) .

3. Press the Remote Keyless Entry (RKE) transmitter's LOCK and UNLOCK buttons at the same time until horn sounds.

If your vehicle does not have RKE, press the Driver Information Center (DIC) vehicle information button until the PRESS V TO RELEARN TIRE POSITIONS message displays, press V button to confirm.

If your vehicle does not have RKE or DIC buttons, press the trip odometer reset stem located on the instrument panel cluster until the RELEARN TIRE POSITIONS message displays press reset to confirm.

The horn sounds twice to signal the receiver is in relearn mode and TIRE LEARNING ACTIVE message displays on the DIC screen.

4. Starting with LF tire, use a TPMS activation tool, or rapidly increase/decrease the pressure to activate the sensor until horn sounds.

5. Repeat step 4 for remaining tires in the following order: RF RR and LR.

6. After completing LR tire, horn will sound twice to signal the sensor matching process has completed.

7. Turn ignition to OFF position to exit vehicle learn mode. Adjust all tires to pressure listed on tire placard.

CN/US Buick LaCrosse 2004.01~2006.12(315MHz)

CN/US Buick Park Avenue 2006.01~2008.12(315MHz)

CN/US Cadillac ATS Sport 2014.01~2015.12(315MHz)

CN/US Cadillac ATS Sport 2013.01~2013.12(315MHz)

CN/US Cadillac CTS-V 2009.01~2013.12(315MHz)

CN/US Cadillac CTS-V(Sport) 2014.01~2015.12(315MHz)(15268606)

AU/CN/US Cadillac DTS 2005.01~2006.12(315MHz)(15268606)

AU/CN/US Cadillac STS 2009.01~2011.12(315MHz)(Clamp in)

AU/CN/US Chevrolet Caprice 2011.01~2013.12(315MHz)

AU/KR/US Chevrolet Corvette 2013.01~2013.12(315MHz)

AU/KR/US Chevrolet Corvette 2010.01~2011.12(315MHz)

CN/US Chevrolet Equinox 2009.01~2009.12(315MHz)(Clamp in)

CN/US Chevrolet Equinox 2008.01~2008.12(315MHz)(Clamp in)

CN/US Chevrolet Equinox 2007.01~2007.12(315MHz)

CN/US Chevrolet G Series 2008.01~2008.12(315MHz)

CN/JP/US Chevrolet HHR 2009.01~2010.12(315MHz)(Clamp in)

CN/KR/US Chevrolet Impala 2007.01~2007.12(315MHz)(Clamp in)

CN/US Chevrolet Impala 2006.01~2006.12(315MHz)

CN/US Chevrolet Monte Carlo 2007.01~2009.12(315MHz)(Clamp in)

CN/US Chevrolet Monte Carlo 2006.01~2006.12(315MHz)(Clamp in)

CN/US Chevrolet Uplander 2008.01~2009.12(315MHz)

AU Chevrolet Uplander 2004.01~2010.12(315MHz)

CN/US GMC Sierra Classic 2007.01~2007.12(315MHz)

CN/US Saturn Lambda 2007.01~2008.12(315MHz)

AU Holden Caprice 2014.01~2017.12(315MHz)

AU Holden Caprice 2011.01~2013.12(315MHz)

AU Holden Equinox 2009.01~2009.12(315MHz)

AU Holden Equinox 2008.01~2008.12(315MHz)

AU HSV Grange 2011.01~2013.12(315MHz)
