Ascent

Ascent

Description
Technical Support
Other Vehicles Uses This Sensor
Sensor manufacturer 433MHz
Sensor frequency
Sensor part number 28103FL000/28103FL00A
Sensor printing number 28103FL000/FL00A
Learning type O/A
Tire nut torque value (Nm)


Relearn procedure:

General recommended method of use:

1. Long press the TPMS button until the screen displays TPMS1, then long press the TPMS button until the screen displays TPMS1 SET, and finally long press the TPMS button until the screen does not display TPMS1 SET is to set the TPMS standard mode successfully.

2.Stop and turn off the lock car for more than 20 minutes, and then start the vehicle at a speed of 30km/h or more as far as possible to maintain a constant speed for more than 15 minutes, until the instrument panel shows the tire pressure data of 4 tires or the tire pressure data of 4 tires are refreshed, that is, the automatic match is successful, if not, please repeat this stop and turn off and drive for more than 15 minutes of operation 2 to 3 times.

Conservative use method:

1.Use OBD learning to learn the 4 sensor ids into the vehicle tire pressure system and clear the fault code.

2.Long press the TPMS button until the screen displays TPMS1, then long press the TPMS button until the screen displays TPMS1 SET, and finally long press the TPMS button until the screen does not display TPMS1 SET to set the TPMS standard mode successfully.

3.Stop and turn off the lock car for more than 20 minutes, and then start the vehicle at a speed of 30km/h or more to maintain a constant speed for more than 30 minutes, until the instrument panel shows the tire pressure data of 4 tires or the tire pressure data of 4 tires are refreshed, that is, the automatic match is successful, if not, please repeat the operation of stopping and turning off and driving for more than 30 minutes 2 to 3 times.

CN/EU/RU/US Subaru Ascent 2018.01~2024.12(433MHz)

AU Subaru Crosstrek 2023.01~2024.12(433MHz)

CN/EU/RU/US Subaru Crosstrek 2018.01~2024.12(433MHz)

EU/RU/US Subaru Evoltis 2020.01~2023.12(433MHz)

EU/RU Subaru Forester 2019.01~2024.12(433MHz)(S5.SK)

CN Subaru Forester 2018.01~2024.12(433MHz)(FM5.PF3)

AU/US Subaru Forester 2018.01~2024.12(433MHz)

EU/RU Subaru FORESTER E-BOXER 2019.09~2024.12(433MHz)

AU/CN/EU/RU Subaru Impreza 2016.09~2024.12(433MHz)(HR3)

US Subaru Impreza 2016.09~2024.12(433MHz)

EU/RU Subaru Impreza e-Boxer 2020.01~2022.12(433MHz)

CN/EU/RU/US Subaru Legacy 2017.05~2024.12(433MHz)

EU/RU Subaru Levorg 2021.03~2023.12(433MHz)(VN)

AU Subaru Levorg 2021.03~2022.12(433MHz)

AU Subaru Libery 2018.01~2023.12(433MHz)

AU Subaru Outback 2018.01~2024.12(433MHz)(BS.BT)

US Subaru Outback 2018.01~2024.12(433MHz)

CN/EU/RU Subaru Outback 2017.01~2024.12(433MHz)

CN Subaru Tribeca 2021.01~2024.06(433MHz)

AU/CN/EU/RU Subaru Tribeca 2017.01~2020.12(433MHz)

AU/US Subaru WRX 2022.01~2023.12(433MHz)(MRXSHR3)

CN/EU/RU Subaru WRX 2019.01~2024.06(433MHz)(MRXSHR3)

AU Subaru WRX 2019.01~2021.12(433MHz)

AU Subaru XV 2018.01~2023.12(433MHz)(GT)

CN/EU/RU/US Subaru XV 2017.03~2024.06(433MHz)

US Subaru XV Crosstrek 2023.01~2023.12(433MHz)

US Subaru XV Crosstrek 2017.04~2020.12(433MHz)

EU/RU Subaru XV E-BOXER 2020.01~2024.12(433MHz)
