B-MAX

Sensor manufacturer	315MHz
Sensor frequency
Sensor part number	9L3Z1A189A
Sensor printing number	9L3T-1A180-AE/9L3T-1A180-AF/9L3T-1A180-BB/9L3T-1A180-BD/9L3T-1A180-CA/9L3T-1A150-BE
Learning type	S
Tire nut torque value (Nm)

With Standard Ignition-Relearn Procedure:

1. Inflate all tires to the pressure indicated on tire placard.

2. Turn the ignition to the OFF position and depress brake pedal for one second then release.

3. Turn ignition from OFF to ON for 3 times and stop at ON position (dashboard completely lights on) .

4. Depress brake pedal for one second then release.

5. Turn the ignition to the OFF position.

6. Turn ignition from OFF to ON for 3 times and stop at ON position.

7. When come into training mode, horn will sound and TPMS indicator will flash. 'TRAIN LF TIRE' will appear on message center (if available) . Use TPMS relearn tool to activate sensor, horn will sound to indicate a successful sensor recognition. Repeat this step for RF RR and LR tires.

8. 'TRAINING MODE COMPLETE' will be displayed in the message center after LR tire has been trained. For vehicle without message center display, turn the ignition to the OFF position, the horn will not sound if the training is successfully completed. Repeat the training steps if the horn sounds.

PUSH-BUTTON START-01 (If press the start button only once to enter the ACC mode, see the under relearn procedure , else if have to press twice to enter the ACC mode, please see the next relearn procedure ) , Relearn Procedure:

1. Inflate all tires to the pressure indicated on tire placard.

2. Push the START button to the OFF position and depress brake pedal for one second then release.

3. Press START button 5 times.

4. Depress brake pedal for one second then release.

5. Press START button 6 times.

6. When come into training mode, horn will sound and TPMS indicator will flash. 'TRAIN LF TIRE' will appear on message center (if available) . Use TPMS relearn tool to activate sensor, horn will sound to indicate a successful sensor recognition. Repeat this step for RF RR and LR tires.

7. 'TRAINING MODE COMPLETE' will be displayed in the message center after LR tire has been trained. For vehicle without message center display, turn the ignition key to the OFF position, the horn will not sound if the training is successfully completed. Repeat the training steps if the horn sounds.

PUSH-BUTTON START-02, Relearn Procedure:

1. Inflate all tires to the pressure indicated on tire placard.

2. Push the START button to the OFF position and depress brake pedal for one second then release.

3. Press START button 8 times.

4. Depress brake pedal for one second then release.

5. Press START button 9 times.

6. When come into training mode, horn will sound and TPMS indicator will flash. 'TRAIN LF TIRE' will appear on message center (if available) . Use TPMS relearn tool to activate sensor, horn will sound to indicate a successful sensor recognition. Repeat this step for RF RR and LR tires.

7. 'TRAINING MODE COMPLETE' will be displayed in the message center after LR tire has been trained. For vehicle without message center display, turn the ignition key to the OFF position, the horn will not sound if the training is successfully completed. Repeat the training steps if the horn sounds.

Warning:

Turn the hazard flashers on then off

three times to start the stationary relearn procedure can't relearn the new ID, it only can relearn the ID position when rotating tires.

CN/US Ford C-Max 2017.01~2020.12(315MHz)

CN/US Ford C-Max 2014.01~2016.12(315MHz)

CN/US Ford C-Max 2013.01~2013.12(315MHz)

CN/US Ford C-Max 2012.01~2012.12(315MHz)

CN/JP/US Ford Ecosport 2015.06~2017.06(315MHz)

CN/EU/RU/US Ford Edge 2013.01~2014.12(315MHz)

CN/EU/RU/US Ford Edge 2012.01~2012.12(315MHz)

CN/EU/RU/US Ford Edge 2011.01~2011.12(315MHz)

CN/EU/RU/US Ford Edge 2010.07~2010.12(315MHz)

AU/CN/US Ford Escape 2018.01~2019.12(315MHz)

AU/CN/US Ford Escape 2016.01~2017.12(315MHz)

AU/CN/US Ford Escape 2015.01~2015.12(315MHz)

AU/CN/US Ford Escape 2013.10~2014.12(315MHz)

AU/CN/US Ford Escape 2013.01~2013.09(315MHz)

AU/CN/US Ford Escape 2012.01~2012.12(315MHz)

CN/US Ford Escape 2008.06~2011.12(315MHz)(9L3Z1A189A)

CN/US Ford E-Series 2020.01~2020.12(315MHz)

CN/US Ford E-Series 2018.01~2019.12(315MHz)

CN/US Ford E-Series 2009.08~2017.12(315MHz)

AU Ford Everest 2018.01~2019.12(315MHz)

AU Ford Everest 2009.06~2017.12(315MHz)

AU Ford Expedition 2018.01~2018.12(315MHz)

CN/US Ford Expedition 2015.01~2017.12(315MHz)

CN/US Ford Expedition 2010.08~2014.12(315MHz)

CN/EU/JP/RU/US Ford Explorer 2013.01~2015.09(315MHz)

CN/EU/JP/RU/US Ford Explorer 2012.01~2012.12(315MHz)

AU/KR Ford Explorer 2011.01~2015.12(315MHz)

CN/EU/JP/RU/US Ford Explorer 2010.11~2011.12(315MHz)(9L3Z1A189A)

CN/US Ford F-150 2011.01~2014.12(315MHz)

CN/US Ford F-150 2009.01~2010.12(315MHz)(P415)

CN/US Ford F-150 HD 2011.01~2014.12(315MHz)

CN/US Ford Fiesta 2018.01~2020.12(315MHz)

CN/US Ford Fiesta 2014.01~2017.12(315MHz)

CN/US Ford Fiesta 2011.01~2013.12(315MHz)

CN/EU/RU/US Ford Flex 2020.01~2021.12(315MHz)

CN/US Ford Flex 2013.01~2019.12(315MHz)(D471)

CN/EU/RU/US Ford Flex 2012.01~2012.12(315MHz)

CN/EU/RU/US Ford Flex 2010.05~2011.12(315MHz)

CN/US Ford Focus 2014.01~2020.12(315MHz)

CN/US Ford Focus 2013.01~2013.12(315MHz)

CN/US Ford Focus 2012.01~2012.12(315MHz)

CN/US Ford Focus 2009.07~2011.12(315MHz)(9L3Z1A189A)

CN/US Ford Focus RS 2016.01~2017.12(315MHz)

CN/US Ford F-Series 2009.01~2014.12(315MHz)

CN/US Ford F-Series SD 2012.01~2016.12(315MHz)

CN/US Ford F-Series SD 2011.01~2011.12(315MHz)

CN/US Ford F-Series SD 2010.06~2010.12(315MHz)(Snap in)

CN/US Ford Fusion 2013.07~2016.03(315MHz)

CN/US Ford Fusion 2012.07~2013.06(315MHz)

CN/US Ford Fusion 2009.02~2012.06(315MHz)

CN/US Ford Interceptor Explorer 2015.01~2015.08(315MHz)

CN/US Ford Interceptor Explorer 2011.01~2014.12(315MHz)

CN/US Ford Interceptor Taurus 2011.01~2019.12(315MHz)

CN/JP/US Ford Mustang 2012.01~2014.09(315MHz)

CN/JP/US Ford Mustang 2010.01~2011.12(315MHz)

CN/US Ford Mustang 2009.03~2009.12(315MHz)

CN/US Ford Ranger 2018.01~2018.12(315MHz)

CN/US Ford Ranger 2012.01~2017.12(315MHz)

CN/US Ford Shelby GT500 2012.01~2014.12(315MHz)

US Ford Special Service Police Sedan 2014.01~2017.12(315MHz)

CN/EU/RU/US Ford Taurus 2019.01~2021.12(315MHz)

CN/US Ford Taurus 2018.01~2018.12(315MHz)

CN/EU/RU/US Ford Taurus 2017.01~2017.12(315MHz)

CN/EU/RU/US Ford Taurus 2016.01~2016.12(315MHz)

CN/EU/RU/US Ford Taurus 2012.11~2015.12(315MHz)

CN/EU/RU/US Ford Taurus 2012.01~2012.10(315MHz)

CN/EU/RU/US Ford Taurus 2011.01~2011.12(315MHz)

CN/EU/RU/US Ford Taurus 2010.05~2010.12(315MHz)(Snap in)

AU Ford Territory 2011.01~2015.12(315MHz)

AU/CN/US Ford Transit 2017.01~2019.12(315MHz)

AU/CN/US Ford Transit 2016.01~2016.12(315MHz)

AU/CN/US Ford Transit 2015.01~2015.12(315MHz)

AU/CN/US Ford Transit 2010.01~2014.12(315MHz)

CN/US Ford Transit Connect 2018.01~2018.12(315MHz)

CN/US Ford Transit Connect 2016.01~2017.12(315MHz)

CN/US Ford Transit Connect 2014.01~2015.12(315MHz)

CN/US Ford Transit Connect 2013.01~2013.12(315MHz)

CN/US Ford Transit Connect 2012.01~2012.12(315MHz)

CN/US Ford Transit Connect 2011.01~2011.12(315MHz)

CN/US Ford Transit Connect 2010.01~2010.12(315MHz)

AU Ford Transit Custom 2013.01~2019.12(315MHz)

CN/US Ford Transit LCV 2014.01~2019.12(315MHz)

AU Ford Transit Van 2013.01~2019.12(315MHz)

CN/US Lincoln CUV 2014.01~2018.12(315MHz)

CN/US Lincoln Mark LT 2008.08~2014.12(315MHz)

CN/US Lincoln MKC 2017.01~2017.08(315MHz)

CN/US Lincoln MKC 2016.01~2016.12(315MHz)

CN/US Lincoln MKC 2014.04~2015.12(315MHz)

CN/KR/US Lincoln MKS 2017.01~2020.12(315MHz)

CN/US Lincoln MKS 2013.01~2016.12(315MHz)

CN/KR/US Lincoln MKS 2011.01~2012.12(315MHz)

CN/US Lincoln MKT 2018.01~2021.12(315MHz)

CN/US Lincoln MKT 2016.01~2017.12(315MHz)

CN/US Lincoln MKT 2013.01~2015.12(315MHz)

CN/US Lincoln MKT 2010.08~2012.12(315MHz)

CN/US Lincoln MKX 2011.01~2015.07(315MHz)

CN/US Lincoln MKX 2010.07~2010.12(315MHz)

CN/US Lincoln MKZ 2015.01~2016.12(315MHz)

CN/US Lincoln MKZ 2013.01~2014.12(315MHz)

CN/US Lincoln MKZ 2010.01~2012.12(315MHz)

CN/US Lincoln MKZ 2009.02~2009.12(315MHz)(9L3Z1A189A)

CN/US Lincoln Navigator 2016.01~2017.12(315MHz)

CN/US Lincoln Navigator 2015.01~2015.12(315MHz)

CN/US Lincoln Navigator 2010.08~2014.12(315MHz)

CN/JP/KR/US Lincoln Town Car 2012.01~2013.12(315MHz)

CN/US Lincoln Zephyr 2009.02~2012.12(315MHz)

CN/US Mercury Mariner 2011.01~2013.12(315MHz)

CN/US Mercury Mariner 2010.01~2010.12(315MHz)

CN/US Mercury Mariner 2009.01~2009.12(315MHz)

CN/US Mercury Milan 2012.01~2012.12(315MHz)

AU/CN/JP/KR/US Ford Interceptor Explorer 2011.01~2015.12(315MHz)

AU/CN/JP/KR/US Ford Interceptor Taurus 2011.01~2019.12(315MHz)

US Ford F-250 2010.01~2016.12(315MHz)

US Ford Super Duty 2016.01~2016.12(315MHz)

AU/CN/JP/KR/US Ford C-Max 2012.01~2020.12(315MHz)

AU/JP/KR Ford E-Series 2010.01~2020.12(315MHz)

AU/CN/JP/KR/US Ford Ecosport 2015.01~2018.12(315MHz)

US Ford F-450 2015.01~2016.12(315MHz)

AU/CN/JP/KR/US Ford Focus RS 2016.01~2017.12(315MHz)

AU/JP/KR Ford Transit LCV 2014.01~2019.12(315MHz)

AU/CN/JP/KR Ford Econoline 2006.01~2018.12(315MHz)

AU/CN/JP/KR Lincoln CUV 2014.01~2018.12(315MHz)

AU/CN/JP/KR Lincoln Mark LT 2009.01~2014.12(315MHz)

AU/CN/JP/KR Lincoln MKT 2011.01~2017.12(315MHz)

CN/US Mercury Milan 2009.02~2009.12(315MHz)(9L3Z1A189A)

CN/US Mercury Milan 2010.01~2011.12(315MHz)
