GLS SUV

Sensor manufacturer	433MHz
Sensor frequency
Sensor part number	A0009058706
Sensor printing number	A0009058706
Learning type	O/A
Tire nut torque value (Nm)

Relearn New Sensor IDs.

Ensure all tires are inflated to the pressure listed on the tire placard. Vehicle must be driven for at least 10 minutes, while maintaining speed above 16 mph in order for system to learn new sensor Ids. If spare tire sensor Id is being programmed, a TPMS tool is necessary.

NOTE: The drive speed should be controlled between 16 mph (25km/h) and 64 mph (100km/h) .

RESET Tire Pressure:

1. Inflate all tires to the pressure indicated on tire placard.

2. Turn ignition to ON position (engine off) .

3. Press 'forward/back' button on steering wheel until trip and odometer are displayed.

4. Press 'UP/DOWN' button until tire inflation pressure monitor is displayed.

5. Hold down reset button (located on instrument cluster) until 'MONITOR CURRENT TIRE PRESSURE?' Is displayed.

6. Press '+' button 'TIRE PRESS, MONITOR ACTIVATED-PRESS. DISPLAY AFTER DRIVING A FEW MINS. ' Is displayed.

7. If 'REATIVE-TIRE PRESS. MONITOR!' Appears, repeat relearn procedure.

8. If 'TIRE PRESSURE-CHECK TIRES!' Appears, indicates tire pressure too low, adjust pressures accordingly

AU/JP/US Maybach S Series 2021.01~2024.12(433MHz)(223)

AU/JP/KR/US Mercedes AMG GT 2023.06~2024.12(433MHz)(A0009058706)

CN/EU/RU Mercedes AMG GT 2022.01~2024.12(433MHz)(192)

US Mercedes AMG SL 2021.09~2023.12(433MHz)

AU/US Mercedes C Class 2021.06~2024.12(433MHz)(206)

JP/KR Mercedes C Class 2021.06~2024.12(433MHz)

CN Mercedes C Class 2021.01~2024.06(433MHz)(206)

CN/EU/RU Mercedes CLE Class 2022.01~2024.12(433MHz)

AU/US Mercedes CLE Class 2022.01~2024.12(433MHz)

KR Mercedes CLS Class 2021.01~2022.12(433MHz)

CN Mercedes E Class 2021.01~2023.12(433MHz)(214)

AU/JP/KR/US Mercedes EQE 2022.01~2024.12(433MHz)

CN/EU/RU Mercedes EQE 2022.01~2024.12(433MHz)

AU/JP/KR/US Mercedes EQS 2021.01~2024.12(433MHz)

CN/EU/RU Mercedes EQS 2021.01~2024.12(433MHz)

CN/EU/RU Mercedes GLC Class 2022.06~2024.12(433MHz)(254)

AU/KR/US Mercedes GLC Class 2022.06~2024.12(433MHz)(254)

CN Mercedes GLK Class 2022.01~2023.12(433MHz)

AU/JP/KR/US Mercedes S Class 2020.01~2024.12(433MHz)(W223)

CN/EU/RU Mercedes S Class 2020.01~2024.12(433MHz)(W223)

AU/EU/JP/KR/RU/US Mercedes SL Class 2021.09~2024.12(433MHz)

CN Mercedes SL Class 2021.09~2024.12(433MHz)

EU/RU Mercedes C Class 2021.06~2024.12(433MHz)
