1) Works with all OBDII/EOBD compliant cars, light-duty trucks, SUVs, minivans and hybrid sold worldwide
2) One-key emissions status test
3) Red-Yellow-Green LEDs and build-in speaker indicate emissions monitor status
4) Reads codes, clears codes, turns off Check Engine Light (MIL) and resets monitors
5) Displays complete live data stream
6) Reads freeze frame data
7) Shows live vehicle sensors data in text and graph formats
8) Retrieves VIN number
9) Multilingual menu options and code definitions
10) Life time FREE software via USB cable
Model | NT204 |
Display | 2.4" TFT color screen |
Operating Temperature | 0-60℃ (32 to 140℉) |
Storage Temperature | -20 to 70℃ (-4 to 158℉) |
Power | 8 to 18 V provided via vehicle |
Supported Protocols | J1859-41.6, J1850-10.4, ISO9141, KWP2000 (ISO 14230), and CAN (Control Area Network ISO 11898) |
Dimensions | 120mm*75mm*20mm |
Weight | 0.3kg |
QTY/CTN | 60SETS |
Weight/CTN | 21.5KG |
CTN MEAS | 530*525*336mm |
