Features a 5.5'' TFT Capacitive LCD Touchscreen that will respond to glove use
- Provides easy diagnosis on multiple vehicle makes
- Works on both OBDI and OBDII vehicles including the latest 2020/2021 models
- Identifies cars quickly and easily with one-key VIN reading
- Reads and clears codes of all electronic modules
Supports the most common required service functions including Oil Reset, EPB, TPS, SAS, TPMS, DPF, Injecotr and ABS Bleeding etc.
- Shows live sensors data and provides data graphing
- Merges PID graphs for easy and intuitive diagnosis
- Displays freeze frame data
- Retrieves ECU information
- Multilingual menu options and code definitions
One Touch Update via WIFI makes the scanner keep the latest system status at all times
| Item | Description |
| Screen | 5.5'' diagonal, daylight readable color LCD screen; 1280*720 pixel |
| Operation System | Android 9.0 |
| Memory | 1GB DDR4 |
| SSD Hard drive | 32GB |
| Communication interface | Built-in WIFI 802.11 b/g/n Wireless LAN |
| USB2.0 OTG/standard USB 2.0 HOST | |
| Bluetooth specification v2.1+EDR; Bluetooth 4.0 Low Energy (LE) (10-20 m) | |
| Built-in Battery | 4000mAh, Lithium-polymer battery, chargeable via 5V USB power supply |
| Protocols | ISO9141-2, ISO14230-2, ISO15765-4, K/L lines, Double K Line SAE-J1850 VPW,SAE-J1850PWM,CAN ISO 11898, High-speed, Middle-speed, Lows-peed and Single wire CAN, KW81, KW82, GM UART, UART Echo Byte Protocol, Honda Diag-H Protocol, TP2.0, TP1.6, SAE J1939, SAE J1939, SAE J1708,Fault-Tolerant CAN |
| Working Temperature | -10 to 70°C |
| Storage Temperature | -20 to 80°C |
| Operating Humidity | 5%-95% Non-Condensing |
| Dimensions | 236*124*38mm (L*W*H) |
| Weight | 0.87kg (Main unit) |
